Semiconductor marking machine
Feature:
- It adopts imported semiconductor array, and 1064nm laser output is obtained by 808nm wavelength semiconductor emitting diode pumped Nd:YAG Medium .The laser has the advantages of small in size (equal 1/4 of the conventional size),high photoelectric conversion efficiency, good light beam mode, and no maintenance, applicable to marking or engraving metal material and some nonmetallic material in different design and text, and especially suitable for various production line of online marking.
- The machine use the computer control, has the advantage of easy operation, small size ,low power consumption ,high efficiency, long service life, no maintenance, high precision ,high stability, full seal structure for optical system, can light path preview and have focus instruction function, low noise etc. It is proven to be a high cost performance ratio machine and popular among the customer.
| Model No | HSDP-50W | HSDP-75W | HSDP-100W |
|---|---|---|---|
| wavelength | 1064nm | 1064nm | 1064nm |
| output power | 50W | 75W | 100w |
| Repetition rate | ≤50kHz | ≤50kHz | ≤50kHz |
| marking scope | 70X70mm、110mm×110mm、140×140 mm、175×175（optional） | 70X70mm、110mm×110mm、145×145 mm、175×175（optional） | 70X70mm、110mm×110mm、145×145 mm、175×175（optional） |
| marking depth | ≤0.3mm | ≤0.3mm | ≤0.6mm |
| marking speed | ≤7000mm/s | ≤12000mm/s | ≤12000mm/s |
| Min.line width | 0.015mm | 0.015mm | 0.015mm |
| Min.chars. | 0.3mm | 0.3mm | 0.3mm |
| Location&repeatability precision | ±0.003mm | ±0.003mm | ±0.003mm |
| power supply | AC220V±10%/ 50Hz | AC220V±10%/ 50Hz | AC220V±10%/ 50Hz |
| whole power | 2KW | 2KW | 2KW |
| location | ＜5mW LD RED RAY ,wavelength 650nm＜5mW | ＜5mW LD RED RAY ,wavelength 650nm＜5mW | LD RED RAY ,wavelength 650nm＜5mw |
| circulating water | Deionized water, distilled water | Deionized water, distilled water | Deionized water, distilled water |
